Feature Description｜SDK Event Data Format and Validation Guide

This article describes the data format required when the Crescendo Web SDK receives behavior events. If the data structure does not meet the specifications below, the event cannot be written to the system, resulting in broken tracking and failed automation triggers.

For installation, see: Tutorial | SDK Web Behavior Tracking Tool;

To check installation and event tracking status, see: Tutorial | Web SDK Installation Verification and Event Tracking Check

Table of Contents

• Event Overview
• page_view — Page View
• add_to_cart / remove_from_cart — Cart Events
• purchase — Purchase
• WebSDK Identify — Member Identity Resolution
• Verifying That Events Are Sent Correctly
• Common Error Reference

The SDK currently supports the following three event types. All events are called using the same method:

clWidget.clSdk.clRe.record("event_name", { props: { ... } });

Event Name	Trigger Timing	Required Fields
page_view	User enters any page	page_path, page_title
add_to_cart	User adds an item to the cart	items (including item_id, item_name, price, quantity)
remove_from_cart	User removes an item from the cart	Same as add_to_cart
purchase	User completes checkout and payment	transaction_id, revenue, items

⚠️ Do not use multiple event sources at the same time. For example, enabling both the GA4 dataLayer and the Event Tracking API will cause events to be written twice. Each website can use only one sending method.

---

page_view｜Page View

Triggered when a user enters any page. page_view is also the first validation metric to confirm after installation is complete.

Field Specifications

Field	Type	Required	Description
props.page_path	String	Required	The URL path of the current page, e.g. /products/shirt
props.page_title	String	Required	The <title> text of the current page

Code Example

clWidget.clSdk.clRe.record("page_view", {
  props: {
    page_path: "/products/shirt",
    page_title: "Summer Cotton T-Shirt | Brand Official Site",
  },
});

---

add_to_cart / remove_from_cart｜Cart Events

Triggered when an item is added to or removed from the cart. Both events use exactly the same data structure; only the event name differs.

Event-Level Fields

Field	Type	Required	Description
props.items	Array	Required	Array of items; must contain at least one item object
props.currency	String	Optional	Currency code (ISO 4217), e.g. TWD, USD

items Array — Fields for Each Item Object

Field	Type	Required	Description
item_id	String	Required	Unique product identifier (SKU or product ID)
item_name	String	Required	Product name
price	Number	Required	Unit price; must be a Number type (do not send the string "490"). This field is also required data for the dynamic cards in Cart Retargeting, so make sure it is not empty.
quantity	Number	Required	Quantity; must be a Number type
description	String	Optional	Product description text
affiliation	String	Optional	Brand or store affiliation name
coupon	String	Optional	Item-level coupon code
discount	Number	Optional	Item discount amount
index	Number	Optional	The item's position in the list (starting from 1)
item_brand	String	Optional	Product brand name
item_category	String	Optional	Product category (first level)
item_category2 ~ 5	String	Optional	Product category (second to fifth level)
item_list_id	String	Optional	ID of the list the item belongs to
item_list_name	String	Optional	Name of the list the item belongs to
item_variant	String	Optional	Product variant (e.g. color, size)
link	String	Optional	Product page URL
image_link	String	Optional	Product image URL
location_id	String	Optional	Location ID of the item (Google Places ID format)

Code Example

// Add to cart
clWidget.clSdk.clRe.record("add_to_cart", {
  props: {
    currency: "TWD",
    items: [
      {
        item_id: "SKU_67890",        // Required
        item_name: "Summer Cotton T-Shirt",  // Required
        price: 490,                  // Required: Number, do not send "490" as a string
        quantity: 1,                 // Required: Number
        item_brand: "Brand Name",
        item_category: "Apparel",
        item_variant: "White / M",
        link: "https://example.com/products/shirt",
        image_link: "https://example.com/images/shirt.jpg",
      },
    ],
  },
});

// Remove from cart (same structure, only the event name differs)
clWidget.clSdk.clRe.record("remove_from_cart", {
  props: {
    currency: "TWD",
    items: [
      {
        item_id: "SKU_67890",
        item_name: "Summer Cotton T-Shirt",
        price: 490,
        quantity: 1,
      },
    ],
  },
});

---

purchase｜Purchase

Triggered after a user completes checkout and payment. This event is the core basis for Cart Retargeting and conversion tracking, so make sure all required fields are complete.

Event-Level Fields

Field	Type	Required	Description
props.transaction_id	String	Required	Unique order identifier. The system uses this field for deduplication; sending the same ID again will not be counted twice
props.revenue	Number	Required	Total order amount; must be a Number type
props.items	Array	Required	Array of order items; field structure is the same as add_to_cart
props.currency	String	Optional	Currency code (ISO 4217), e.g. TWD
props.tax	Number	Optional	Tax amount
props.shipping	Number	Optional	Shipping fee
props.coupon	String	Optional	Order-level coupon code

⚠️ Do not use a sequential number or timestamp for transaction_id. We recommend using the original order number from your order system to ensure global uniqueness.

Code Example

clWidget.clSdk.clRe.record("purchase", {
  props: {
    transaction_id: "ORDER_20240101_001",  // Required: order ID
    revenue: 980,                          // Required: Number
    currency: "TWD",
    tax: 0,
    shipping: 0,
    coupon: "SUMMER_SALE",
    items: [
      {
        item_id: "SKU_67890",        // Required
        item_name: "Summer Cotton T-Shirt",  // Required
        price: 490,                  // Required: Number
        quantity: 2,                 // Required: Number
        item_variant: "White / M",
      },
    ],
  },
});

---

WebSDK Identify｜Member Identity Resolution (Updated 2026.06)

After a visitor logs in or registers on your website, you can use WebSDK Identify to pass the member's identity to Crescendo, resolving the visitor's previously anonymous browsing footprint to an existing member. This is what enables accurate automated messaging and segmentation afterward.

It uses the same dataLayer mechanism as GA4: after a successful login or registration, simply push a clIdentity event to window.dataLayer. No additional API call is required.

User logs in　→　dataLayer.push(clIdentity)　→　SDK detects the event　→　Synced to MAAC　→　Precise marketing

⚠️ Precondition: Enable "Website Tracking" for the Web Channel first. If it is not enabled, the system will not save member data and will not return any error message, even if clIdentity is pushed correctly. Path: Admin Center > Channel Settings > Website > General Settings.

① What to do: push the event after a successful login or registration

Push the following event in a frontend flow where the identity has been confirmed (for example, a successful login callback). customerId is required; all other fields are optional. If customerId is not provided, the system will not create or update member data.

window.dataLayer = window.dataLayer || [];
window.dataLayer.push({
  event: "clIdentity",
  params: {
    customerId: "REQUIRED_UNIQUE_ID", // Required: your platform's user ID
    email: "[e-mail]",        // Optional
    name: "John Doe",                 // Optional
    phone: "[phone]",           // Optional (E.164 format)
    gender: "male",                   // Optional (male/female/other/unknown)
    birthday: "1995-01-01",           // Optional (YYYY-MM-DD)
    address: "123 Main St, ..."       // Optional
  }
});

② Field Specifications

Field	Required	Format / Notes	Mapped Field
customerId	Required	String; we recommend using a stable, unchanging member ID	customer_id
email	Optional	Must be a valid email format	display_email
name	Optional	String	display_name
phone	Optional	Must include the country code (E.164 format), e.g. [phone]; numbers without a country code are treated as invalid and skipped	display_mobile
gender	Optional	Accepts male, female, other, unknown	gender
birthday	Optional	Format is YYYY-MM-DD	birth
address	Optional	String	address

📌 Behavior when an optional field has an invalid format: If an optional field is in an incorrect format (for example, gender is not one of the values above, phone is missing the country code, or birthday is not in YYYY-MM-DD format), the system will skip that field but still create/update the member. The whole record will not fail, and no error is returned. Please verify that each field is in the correct format before going live.

③ When to Call

Timing	Push clIdentity?	Description
Member login succeeds	✅ Push	A stable member ID is available; this is the primary identification point
Member registration completes	✅ Push	First-time identification of a new member
User logs out	❌ Not required	The SDK automatically maintains the current identity; when switching users, simply push again once the new user logs in
Visitor browsing (not logged in)	❌ Do not push	There is no stable customerId; do not push for anonymous visitors

④ How to Confirm Identification Succeeded (Verification)

Member identity resolution is not covered by the "Event Tracking Check" tool. Please confirm it using the steps below:

1. Confirm that "Website Tracking" is enabled for the Web Channel (see the precondition above).
2. On the login/registration page, open the Console in your browser's developer tools, type dataLayer to inspect it, and confirm that it contains a clIdentity event with customerId correctly populated.
3. Switch to the Network tab and confirm that a POST /api/v1/authenticate request appears after login, with your customer_id in the request payload.
4. Finally, contact the Crescendo Lab Customer Success team to help confirm whether the corresponding member data has been created/updated in the backend.

⑤ Notes and FAQs

I have pushed clIdentity, but I can't find the member data in the backend. What should I do?

This is usually not an "error" but rather a case where one of the conditions is not met, causing the record to be silently skipped (no error message is shown). Please check the following in order:

• Whether "Website Tracking" is enabled for the Web Channel — if not, the entire identify is skipped without an error (the most common cause).
• Whether the pushed params include customerId (required) — without customerId, no member is created or updated.
• Whether the optional fields are in the correct format — phone must include the country code, gender must be male/female/other/unknown, and birthday must be YYYY-MM-DD; fields with invalid formats are skipped, but the remaining fields are still written.
• Use the "④ How to Confirm Identification Succeeded" steps above to check the clIdentity event and the POST /api/v1/authenticate request in the Console / Network tabs.

Reminder: Member identity resolution will not appear in the "Event Tracking Check" tool. Please contact the Crescendo Lab Customer Success team to confirm the member data in the backend instead.

What happens if I push the same customerId repeatedly?

The SDK automatically merges events with the same customerId, updating using a "new overwrites old, ignore empty values" rule, and only re-validates when the data changes. It will not create duplicate member records.

What should I do when a user logs out or switches accounts?

Logging out does not require calling any method; the SDK automatically maintains the current identity. When a new user logs in, simply push the new customerId, and the SDK will create the corresponding mapping automatically. (This avoids losing the mapping on page reload and is consistent with industry recommendations.)

Can customerId be changed afterward?

We do not recommend changing it. customerId is the primary identifier of a member's identity, and changing it will make it impossible to associate historical behavior data. Please use a stable, unchanging member ID as the customerId.

Will a failed clIdentity affect the website?

No. clIdentity is a non-blocking event; even if the subsequent API call fails, it will not affect the normal operation of the website itself. We recommend that developers add a try-catch to log it.

What happens if the same customerId is used on different devices?

They share the same member record and keep it updated; the user's browsing behavior across different devices can all be linked to the same member through the customerId.

---

Verifying That Events Are Sent Correctly

After implementing the tracking code, follow the steps below to verify it yourself, without waiting for support confirmation.

Step 1: Open your browser's developer tools
In Chrome, press F12 (on Mac, Cmd + Option + I), switch to the Console tab, and type datalayer to filter.

Step 2: Contact the Crescendo Lab Customer Success team for final confirmation
Once your own verification passes, contact the Crescendo Lab Customer Success team to confirm whether the backend has correctly received the following events:

• page_view — entering any page
• add_to_cart — adding an item to the cart
• purchase — completing checkout, and confirm that the transaction_id and items data are correct

---

Common Error Reference

Error Condition	Cause	Correct Approach
Event is sent but the backend receives no data	items is sent as an empty array []	items must contain at least one item object
Product data is missing	Any of item_id, item_name, price, quantity is missing	Each item object must include these four required fields
purchase event cannot be matched to an order	transaction_id or revenue was not provided	Both fields are required for purchase
Amount or quantity data is abnormal	price, quantity, or revenue is sent as a string, e.g. "490"	Numeric fields must be sent as a Number type, e.g. 490
Events are counted twice	Multiple event sources are enabled at the same time	Each website can use only one sending method
SDK is not loaded; clWidget is undefined	The GTM code was not published correctly, or the trigger conditions are misconfigured	Confirm that the GTM trigger condition is set to "DOM Ready" and that the container is published

💬 Need further assistance?
Please contact the Crescendo Lab Customer Success team. Providing the following information can speed up troubleshooting:

📌 If you are troubleshooting WebSDK Identify, please also provide: the frontend call flow after login or registration completes, Console / Network screenshots, and whether website identity resolution is enabled for the Web Channel.

• Installation type (self-hosted e-commerce / SHOPLINE / CYBERBIZ / Shopify / 91APP)
• Browser Console screenshot (whether any error messages appear)
• Payload screenshot of the record request in the Console tab
